Product Details:
|
| Wavelength: | 270-280nm | Type: | U535C2F33Z4 |
|---|---|---|---|
| Viewing Angel: | 120degree | Electronic Power: | 1W |
| Radiant Flux Power: | 12-20mw | Warranty: | 5000hours |
| Size: | 3535 | UV Led Size: | 3.70mm×3.70mm×1.86mm |
| High Light: | 150ma 1w UV LED,Electronic 1w UV LED,20mw high flux led |
||
150ma 1w electronic power 12-20mw raditant flux UVC LED
Characteristics:
|
Parameter
|
Symbol
|
Units
|
Value(Continuous current IF=150mA)
|
Value(Intermittent current IF=200mA)
|
|
Peak Wavelength
|
λp
|
nm
|
270-280
|
270-280
|
|
Radiant Flux
|
Φe
|
mW
|
12-20 | 16-24 |
|
Forward Voltage
|
VF
|
V
|
5-9
|
5.5-9
|
|
Thermal Resistance
|
Rth
|
°C/W
|
≦20
|
≦20
|
|
Spectrum Half Width
|
Δλ
|
nm
|
9.2
|
9.5 |
|
View Angle
|
2θ1/2
|
deg
|
120
|
120
|
Features:
