Product Details:
|
| Dimension: | 2.65mm*2.65mm*2mm | Application: | Fluorescence Spectrum Analysis |
|---|---|---|---|
| Peak Wavelength: | 405nm | Voltage: | 3.5-4V |
| Radiant Flux: | 1600-2000mW | Radiation Angle: | 60° |
| Packaging Technology: | Silicone Dispensing |
405nm UV LED BYTECH U325A0V128Z1 uv led chips 60degree 2525size high power
Characteristics of U325A0V128Z1
1, Electrical / Optical Characteristics (Ta=25℃, RH=40%)
| Parameter | Symbol | Units | Value |
| Peak Wavelength | λp | nm | 400-410 |
| Radiant Flux | Φe | mW | 1600-2000 |
| Forward Voltage | VF | V | 3.5-4.0 |
| Thermal Resistance | Rth | °C/W | ≤3 |
| Spectrum Half Width | Δλ | nm | 10 |
| View Angle | 2θ1/2 | deg | 60 |
2, Absolute Maximum Ratings (Ta=25°C, RH=40%)
| Parameter | Symbol | Units | Value |
| DC Forward Current | IFmax | mA | 1000 |
| Maximum Rating Junction Temperature | Tjmax | °C | 125 |
| Operating Temperature Range | Topr | °C | -30 ~ +85 |
| Storage Temperature Range | Tstg | °C | -40 ~ +85 |
Explain for U325A0V128Z1 :
● U: Packaging technology,silicone dispensing
● 3:radiation angle,60°
● 25: package size,2.5mm*2.5mm
● A1: peak wavelength,400-410nm
● V107: LED chip code, vertical chip
● Z1: Zener chip code
Product Application Information
